Space simulation and thermal‑vacuum testing are essential stages in the aerospace product development and verification process. These tests replicate the extreme vacuum and temperature conditions of outer space to ensure that satellites, spacecraft components, sensors, and avionics perform reliably under real mission environments. Central to this capability is a well‑engineered vacuum pump system that can evacuate large chambers to very low pressures while supporting thermal cycling and outgassing control.
This article explains the core vacuum pump technologies used in space simulation and thermal‑vacuum (TVAC) testing chambers, the reasons behind their selection, and how the complete pumping system is configured for aerospace applications.
Space simulation and thermal‑vacuum testing involve placing aerospace hardware into a sealed chamber and reducing the internal pressure to simulate high‑altitude or outer‑space vacuums. Test sequences often include:
Pressure reduction to deep vacuum levels
Controlled temperature cycles from very low to high
Repeatable thermal and pressure profiles for environmental qualification
Thermal‑vacuum chambers may operate down to pressures as low as 10⁻⁷ Torr or better while maintaining temperatures from well below freezing to several hundred degrees Celsius, depending on test requirements.
In aerospace thermal‑vacuum testing, vacuum pumps are not peripheral devices — they are a core part of the test infrastructure with three primary roles:
The inside of a TVAC chamber must approximate outer space pressures so that materials and electronics behave as they would on orbit. Deep vacuum reduces convective heat transfer and simulates the void of space.
The pump system must maintain the low pressure during thermal ramp‑up and thermal soak cycles without introducing contaminants or pressure fluctuations that could compromise test results.
Aerospace hardware and chamber components release gases during heating (outgassing). The vacuum pumping system must cope with elevated gas loads, often without oil‑based contamination.
Aerospace TVAC test chambers employ multi‑stage pumping systems comprised of roughing pumps, high vacuum pumps, and optional specialized vacuum technologies. Each pump type plays a defined role in the vacuum curve from atmospheric pressure down to deep vacuum.
Dry Scroll and Dry Screw Vacuum Pumps
Roughing pumps remove air and bring the chamber down to a transitional pressure range before high vacuum pumps take over. To avoid contamination and ensure high reliability in aerospace environments, oil‑free dry scroll and dry screw pumps are commonly used. They are especially preferred when oil backstreaming could compromise sensitive tests.
Roots and Multistage Roots Pumps
Roots vacuum pumps (dry multistage designs) are often added to accelerate pump‑down. They provide high throughput at intermediate pressures, reducing the time required to reach high vacuum setpoints.
Turbomolecular Pumps (Turbos)
Once the chamber is in the rough vacuum range, high vacuum pumps such as turbomolecular pumps are used to achieve pressures in the 10⁻⁵ to 10⁻⁷ Torr range and below. Turbos are configured with appropriate backing pumps (dry scroll/screw) to avoid stalling and enable continuous operation.
Turbomolecular pumps are critical for:
Deep vacuum attainment
Minimizing residual gas presence
Supporting accurate space simulation
Cryopumps and Advanced UHV Technologies (Optional)
In the most demanding aerospace tests or ultra‑high vacuum (UHV) research, cryopumps provide very low pressure without mechanical contamination, but they require regeneration cycles and specialized operation.
A robust TVAC vacuum system is usually a cascaded configuration that combines the strengths of different pump technologies:
Roughing Stage: Dry scroll or dry screw pumps remove bulk air.
Booster Stage: Roots or multistage roots pumps accelerate pump‑down.
High Vacuum Stage: Turbomolecular pumps achieve and maintain deep vacuum levels.
Optional UHV Stage: Cryopumps or getter pumps for ultra‑high vacuum if required.
A well‑designed system integrates automatic valve sequencing and controls to smoothly transition between stages and manage load changes during outgassing and thermal events.
Oil‑free pumping solutions (e.g., dry scroll or dry screw pumps) are prioritized to prevent hydrocarbon backstreaming that could deposit on hardware surfaces or affect sensors inside the test chamber.
Thermal‑vacuum tests cycle through extreme temperatures. Vacuum pumps and piping must be compatible with thermal management strategies, including cold traps or liquid nitrogen cooled baffles in some designs.
Space simulation chambers and vacuum systems are typically designed to meet aerospace environmental test standards, such as ASTM, MIL‑STD‑810, or national space testing norms, ensuring reliability and repeatability.
Wordfik provides engineered vacuum pumping solutions tailored for aerospace space simulation and thermal‑vacuum testing:
Dry Scroll and Dry Screw Vacuum Pumps for contamination‑free roughing
Roots and Multistage Booster Pumps for high throughput pump‑down
Turbomolecular Vacuum Pumps for deep vacuum attainment
Integrated TVAC Vacuum Systems with controls and automation
Wordfik systems are sized and specified based on chamber volume, required ultimate pressure, gas load from outgassing, and test cycle duration, ensuring efficient and stable vacuum performance.
